Cooler Master MWE 650 V3 Bronze ATX 3.1 80 Plus Bronze Certified Power Supply

Key Features

Power Evolved

Cooler Master presents the MWE Bronze V3 230V, the upgraded version of the MWE Bronze featuring ATX 3.1 support, high temperature resilience, a smart DC-to-DC + LLC circuit design, a quiet HDB fan, 80 Plus Bronze efficiency, an embossed cable, and a 5-year warranty.

ATX 3.1 Support

Compliant with ATX 3.1 to fully support a peak power 1.5 times higher than the rated maximum wattage, this unit is ideal for use with the 40 series GPUs.

Embossed Cable

An embossed cable texture provides a softer and overall improved grip with a pleasing aesthetic.​

Quiet HDB Fan

A hydrodynamic bearing fan delivers long-lasting quiet and effective cooling.​

Certified Efficiency

The MWE Bronze V3 230V is certified to achieve more than 88% efficiency at typical loads.​​​​

High Temperature Resilience

A 40°C operating temperature allows for pushing your machine to the limits.​

PSU Calculator

Need help choosing the right power supply for your system? Try out our comprehensive and easy-to-use PSU calculator.

Specifications

Model : MPE-6501-ACABW-3B

ATX Version : ATX 12V Ver. 3.1

PFC : Active PFC

Input Voltage : 200-240V

Input Current : 5A

Input Frequency : 50-60Hz

Dimensions (L x W x H) : 140 x 150 x 86 mm / 5.5 x 5.9 x 3.4 inch

Fan Size : 120mm

Fan Bearing : HDB

Efficiency : >88% @ Typical Load

80 PLUS Rating : 80 PLUS Bronze EU 230V

ErP 2014 Lot 3 : Yes

Operating Temperature : 0-40°C

Power Good Signal : 100 - 150 ms

Hold Up Time : >16ms

MTBF : >100,000 Hours

Protections : UVP / OVP / OPP / OTP / SCP

Regulatory : TUV, CE, FCC, CCC, EAC, RCM, UKCA, RoHS2.0 / BIS, KC (based on region's request.)

ATX 24 Pin Connectors : 1

EPS 8 Pin / 4+4 Pin Connectors : 2

SATA Connectors : 6

Peripheral 4 Pin Connectors : 3

PCI-e 6+2 Pin Connectors : 4

Series : MWE Bronze Series

Category : 500 to 750W

Modular : Non Modular

80 Plus Efficiency : Bronze

Form Factor : ATX

Watts : 650W
